Cards printed on 24pt thick smooth uncoated card stock have a substantial thickness to ensure your cards won't bend and flex. Print all sizes of cards from small cards and business cards to hang tags and postcards with bespoke finishes like foil stamping, edge painting, die-cutting to custom shapes and embossed or debossed elements.
Clubcard prints your cards in full colour on an offset printing press using UV dry inks to achieve optimal colour brightness on this beautiful uncoated stock. Offset printing allows you to design without limitations and to create cards that defy the ordinary.
DESIGN CONSIDERATIONS WHEN EMBOSSING / DEBOSSING
Elements that are embossed will have a mirrored debossed effect on the reverse of the card while debossed elements may show a slight impression on the reverse.
Supply Die Lines As Vector Files
Please supply your die line file in Vector format. If you need help preparing your die line, watch the tutorial video or select the option to have us create your die line for you.
Simple Shapes Save Money
The prices listed are for cards cut to simple custom shapes. If your cards require intricate cutting, we will need to provide a custom estimate. We will let you know if your die line requires a custom estimate during the file check process.
Foil area should be less than 2 square inches
Foil is based on an estimated foil size of around 1" x 2". Full foil coverage, or borders that go around the edge of the card require a larger die and would need to be custom quoted for the additional die size.
Foil Can Fluctuate
With the foil stamping, you can expect some slight shifting throughout the print run between the CMYK and foil layers -- there may be up to 1/16" shift on the placement of the foil. Keep this in mind if you are trying to align foil with other printed artwork on the card. The areas where there is tight registration between the CMYK elements and foil elements may not turn out as expected.
Fine Detail / Small Text Does Not Translate Well To Foil
Fine detail in foil stamped elements can fill in (the center of an "e" or "a" in small type, or fine detail in an image or complex logo).
Leave Wiggle Room for Cutting
During the die-cutting process, there will be a degree of shifting of the cut. A good design leaves a 1/8" critical margin inside the trim line to compensate for this shifting. Art that extends to the edge of the card requires a 1/8" bleed.
Die Cut Holes or Space Between Die Cut Elements Need to Be 1/8"
Any hole or interior shape that will die cut needs to be at least 1/8" in diameter. Say you were die-cutting a letter U shape, the aperture in the U (the space between the two stems) must be at least 1/8". Small cut like this may not be strip away during cutting but a gentle tap will knock it out!
Colours On 24pt Uncoated Stock
Because we use UV inks on this uncoated stock the inks will appear vibrant with a slight sheen on the uncoated surface. Cards with heavy or full ink coverage will not have an overall matte appearance commonly achieved on uncoated stocks.
These Cards are Perfect for Writing on
Write up a storm! Unlike our coated options, these cards work perfect as stamp cards, appointment cards, or a business card that you can scrawl a note across the back. You've found a match.
Not the Best Stock for Small Text
Uncoated stocks are more grainy and fibrous than other stocks, so if you are looking for really sharp lines or micro text a coated stock may be a better choice.
Colour Will Vary
The upside of club-run printing is the shared savings, the downside is that we adjust colour globally to get the best overall colour for shared jobs. This means the colour of club-run printed items will vary through the run and will not match exactly on re-prints. Our Indigo printing service is better suited to colour critical work.
Greys Can Shift
CMYK Process colours in the grey range and de-saturated images can shift in colour throughout the print run and may cause the greys to appear either cooler or warmer. For a neutral grey, we recommend converting all grey values and de-saturated images to true greyscale consisting of K (black) only values.
Your Blue Might Not Really Be Blue
Due to the nature of club-run printing, you may experience colour variation in solid fills of blue. For great blue results we recommend a 30% difference between your Cyan and Magenta levels to ensure a nice rich dark blue, rather than purple.
Die Size Matters
The die line must fit within the size ordered. For example, if you order a 4" x 6" die cut card, your shape must fit within a 4" x 6" boundary.
Technical Specifications + Templates
Die Line: Supply a file that includes a vector path outline indicating the shape and size of your die cut card. Pricing is based on simple shape, so your dieline should be as simple as possible or the order may be placed on hold to quote the complex die.
Foil Stamping: Include a separate file/artboard with these elements coloured with Pantone Black to denote the foil stamping. Alternatively, if you would like to include these elements in the same file, place these elements on a separate layer and coloured with a Pantone colour (typically Pantone Black) that denotes the Foil Stamping.
Embossing / Debossing: Include a separate file/artboard with these elements coloured with Pantone Black to denote the debossing or embossing. Alternatively, if you would like to include these elements in the same file, place these elements on a separate layer and coloured with a Pantone colour (typically Pantone Black) that denotes the Foil Stamping.
Bleeds: all files must have a 1/8" bleed on each side
Live Area: keep all critical text and artwork 1/8" inside the trim
Colours: supply your files in CMYK colour (Pantone/RGB colours will be converted or rejected)
Resolution: 300 dpi minimum (400 dpi preferred)
Fonts: fonts must converted to curves/outlines (we do not accept fonts).
Transparencies: flatten all transparencies
Types Of Files We Accept: MAC & PC files from Photoshop (PSD), Illustrator (EPS or AI), CorelDraw (CDR or EPS), Adobe Acrobat PDF, TIFF or JPEG.
